A container that stacks contents on top of each other. One child is

React

Styled Components

2 contributors

Install stack as a package?

Copied

npm i @bit/grommet.grommet.stack

Set Bit as a scoped registryLearn more

npm config set '@bit:registry' https://node.bit.dev

Component Example

React

Vue

Angular

React Native

Add dependency...

Just

import

any of the 1 million components

and packages in Bit or NPM to the example.

import Button from '@bit/grommet.grommet.button';
import Lodash from 'lodash';

modifieddraft

Stack

A container that stacks contents on top of each other. One child is designated as the guidingChild which determines the size. All other children are placed within that size, either above or below based on their order. Stack is typically used to decorate Meter, Chart, or icons.

Usage

import { Stack } from 'grommet';
<Stack />

Properties

a11yTitle

Custom label to be used by screen readers. When provided, an aria-label will be added to the element.

string

alignSelf

How to align along the cross axis when contained in a Box or along the column axis when contained in a Grid.

start
center
end
stretch

gridArea

The name of the area to place this inside a parent Grid.

string

margin

The amount of margin around the component. An object can be specified to distinguish horizontal margin, vertical margin, and margin on a particular side.

none
xxsmall
xsmall
small
medium
large
xlarge
{
  bottom:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  end:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  horizontal:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  left:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  right:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  start:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  top:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string,
  vertical:
    xxsmall
    xsmall
    small
    medium
    large
    xlarge
    string
}
string

anchor

Where to anchor children from. If not specified, children fill the guiding child’s area.

center
left
right
top
bottom
top-left
bottom-left
top-right
bottom-right

fill

Whether to expand to fill all of the available width and height in the parent container.

boolean

guidingChild

Which child to guide layout from. All other children will be positioned within that area. Defaults to 'first’. Defaults to first.

number
first
last

interactiveChild

Which child to restrict user interaction to. All other children will have user interaction disabled.

number
first
last

Intrinsic element

div

Theme

stack.extend

Any additional style for the control of the Stack component. Expects string | (props) => {}.

Defaults to

undefined
